Drone-mounted MultiPort SDR NMB2W

Product Features:

The wireless broadband ad-hoc network utilizes a new-generation software-defined radio (SDR) platform, offering advantages such as long range, high data rates, rapid network access, fast route switching, flexible networking, 2x2 MIMO support, customizable frequency, rich interface options, compact size, and lightweight design. The radio unit features high integration, low power consumption, and a compact design.

Product Advantages:

High security level with support for multiple encryption methods
Strong Low Probability of Intercept/Low Probability of Detection (LPI/LPD) capabilities, including frequency hopping
Support for multiple operation modes: point-to-point, point-to-multipoint, and multipoint-to-multipoint
Flexible networking topologies: star, chain, mesh, and hybrid configurations

Application Scenarios:

Wireless broadband ad-hoc network equipment is widely used in networking and control of intelligent terminals such as drones, unmanned ground vehicles, unmanned vessels, and robots. It is also applicable in fields including:
Tactical squad networking
Disaster rescue and emergency communications
Smart grid management
Forest fire prevention
Mining operations
Counter-terrorism and special operations
Civil defense and other industrial uses

Technical Parameters
Frequency Range	70MHz to 6GHz
Output Power	2w X2
Modulation	TD-COFDM, BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM, DSSS
Data Transmitting Rate	1 to 70Mbps
Channel Bandwidth	1.25MHz, 2.5MHz, 5MHz, 10MHz, 15MHz, 20MHz, 24MHz, 27MHz
Transmitting Type	video, voice, text, image, file
Receive Sensitivity	-103dBm@5MHz Bw
Operating Mode	Point to Point, Point to MultiPoint, MultiPoint to MultiPoint, dynamic Routing, multi-hop relay, etc.
Range	50 to 150km
Basic Port	2xTNC RF, 1-3xRJ45, Ethernet 100/1000BastT, WiFi AP, GPS, RS232/TTL (UART), Sbus/Bluetooth, 1.2-230.4Kbps, DC input
Auxiliary Port	MIC, SP, PTT, GND, RS485/422, USD2.0 OTG
Battery Capacity	-
Power	12 to 36Vdc
Safety	IP66
Operational Temperature	-40°C to +80°C
Dimensions	11.7 x 6.2 x 1.9cm
Weight	149 grams
