Model: GC2010BT Coal Gas Analyzer
Coal gas/Liquefied gas compounds analysis is important for calorific value measurement and safe production. GC2010BT coal gas analyzer uses gas chromatographic technique to measure the concentration of H2, O2, N2, CH4, CO, CO2, C2H6, C3H8, C4H10 and He etc. in coal gas/liquefied gas.
GC2010BT can be specially configured to measure following compounds according to customer's exact requirement:
• Measure benzene, toluene and xylene in coal gas
• Measure unsaturated hydrocarbon, naphthalene in coal gas
• Measure benzene, naphthalene in lean oil and fat oil
Features
• Uses Thermal Conductivity Detector (TCD)
• Special chromatographic column, fast separation, strong anti-pollution
• High sensitivity, high resolution and fast analysis
• Special software processes data
• Accurate quantitative analysis, good repeatability
Technical specification
• Start-up stabilizing time: ＜1 hour
• Temperature control range: room temperature --- 400℃, 1℃ increment
• Temperature control accuracy: 0.1℃
• Baseline drift
TCD: ≤ 0.2mv/30min
• Baseline noise
TCD: ≤ 0.1mv
• Sensitivity: ≥5000mv.ml/mg
